Up3/oil gear pump for lubricating oil 24v marco

Self-priming electric pumps with helical bronze gears for transferring lubricating oils and viscous liquids. Nickel-plated brass body and stainless steel shaft. Particularly suitable for draining engine sumps with the special tubes kit (OK1) and for engines lubricating operations.

Product Name: UP3/OIL
Voltage (V): 24
Consumption (A): 3
Fuse (A): 4
Self-priming (m): 1
Pressure (bar): 2
Flow rate ø 6 (l/min): 0.3
Flow rate ø 8 (l/min): 1
Flow rate ø 13 (l/min): 5.5
Ports (BSP): 3/8"
Hose (mm): 13
IP Protection: 67
Motor power (W): 90
Weight (kg): 1.4
