Blue solar mppt charger 75v/15a (12/24v-15a) victron

Solar chargers collect energy from your solar panels and store it in your batteries. Using the latest and fastest technology, the BlueSolar maximizes this energy harvest, managing it intelligently to reach the maximum load in the shortest possible time. The BlueSolar takes care of the health of the battery, extending its useful life.

Battery voltage: Automatic selection: 12/24 V.
Rated load current: 15A.
Nominal PV power, 12V: 220W.
Nominal PV power, 24V: 440W.
Max. Short circuit current: 15A.
Automatic load disconnection: Yes, maximum load 15A.
Maximum PV open circuit voltage: 75V.
Maximum efficiency: 98%.
Self-consumption: 12V: 20 mA 24V: 10 mA.
"Absorption" charging voltage: 14.4V / 28.8V (adjustable).
"Float" charging voltage: 13.8V / 27.6V (adjustable).
Charging algorithm: multistage variable.
Temperature compensation: -16 mV / ° C, -32mV / ° C resp.
Continuous / Peak Charge Current: 15A / 50A.
Low voltage load shedding: 11.1V / 22.2V or 11.8V / 23.6V
or BatteryLife algorithm.
Low voltage charge reconnection: 13.1V / 26.2V or 14V / 28V
or BatteryLife algorithm.
Protection: Reverse polarity of the battery (fuse).
Output short circuit / overheating.
Working temperature: -30 to + 60 ° C (full nominal power up to 40 ° C).
Humidity: 95%, non-condensing.
